    i. overview
fxf-type duplex fiber digestion and absorption of imported separator is a prototype, reference design information. the machine is mainly used to separate waste paper pulp in the severity of the debris, and hydraulic pulper from a second broken slurry solution. broken by means of solution of native secondary role hydrapulper the bottom of the sieve sieve can be increased to improve its production capacity.
the machine left the equivalent of a sealed horizontal hydraulic pulper with a severity of impurities cleaner combination, compact, high efficiency, the machine set broken impurity solution ﹑ coarse screening and other functions into one, greatly simplifying the waste treatment processes, reduce energy consumption.
slurry tangentially into the tank, under the action of the impeller speed, the body produces eddy currents in the tank, the centripetal force generated by the light swirl together in the vortex center of the debris and heavy debris was shuaixiang tank wall. gathered in the center tank installed in the front cover of light impurities from the discharge pipe from the light impurities, heavy debris through the slurry discharge pipe into the heavy debris cleaner, cleaner to remove heavy debris through the slurry after the re-sent back into the slurry pipe. heavy debris was removed cleaner debris collected in the tank, through the valve timed emissions.
broken by the second impeller slurry tank solution, after the impeller back into the sieve sieve pulp chamber. screen plasma chamber is a cylindrical sieve drum is divided into inner and outer two parts, one inside the drum sieve drum rotor rotary cleaning sieve drum sieve to avoid clogging. passing through the sieve drum sieve kong jingliang fiber slurry discharge pipe, thick slurry residue from the tail pipe emissions.
ii. technical performance

model	fxf0	fxf1	fxf2	fxf3
production capacity	10-20t/d	20-40t/d	40-70t/d	70-100t/d
into the plasma concentration of	≤3%
into the plasma pressure	0.15-0.25mpa
impeller speed	1300r/min	837r/min	840r/min	810r/min
impeller diameter	ф320mm	ф520mm	ф550mm	ф700mm
into the plasma tube diameter        mm	dg100	dg125	dg125	dg150
good slurry pipe diameter mm	dg100	dg125	dg125	dg150
tail pipe of diameter mm	dg65	dg80	dg80	dg80
light debris row	dg65	dg80	dg100	dg100
discharge tube diameter mm	dg65	dg100	dg125	dg125
heavy debris row	y200l-4/30kw	y250m-4/55kw	y280m-4/90kw	y315s-4/110kw
discharge tube diameter mm	1800kg	3000kg	3500kg	4000kg
motor weight (excluding motor) dimensions	2650×1860 ×1825mm	3050×2267 ×2162mm	3200×2650 ×2055mm	3460×2620 ×2050mm

 the equipment design aperture sieve diameter3mm ----- diameter7, sieve drum with hole and slit-two, pass a diameter1.6----- diameter5, seam has 0.15mm ----- 0.8mm , the user can set options according to their needs.
