slag separator reject separator
uses / features
it is mainly used for occ processing system tailings screening. arranged helical rotor blades rotating at high speed , and baffle means in the role of water , washing effect, and the treated non-fibrous impurities , low moisture content . closed screening, good operating environment.
application / features
used for tailing screen in occ system.
when rotating at high speed, rotor blades in spiral arrangement have strong washing function under the action of shower and baffle plate. so. the impurities after being treated by this equipment will not comprise fiber with low moisture content.
screening is closed and operation environment is good.
the main technical parameters main technical parameters
model zsz1 zsz2
specification standard (mm) φ280 φ380
inlet concentration inlet consistency (%) 1 ~ 3.5 1 ~ 3.5
slag concentration reject consistency (%) 15 ~ 20 15 ~ 20
production capacity capacity (t / d) 10 ~ 20 20 ~ 35
equipped with power power of motor (kw) 37kw 55kw
dimensions ( length l × w w × height h): mm 2610 × 1925 × 1010 3200 × 2020 × 1195
