d型水力碎浆机d model hydrapulper
用途/特点
d型水力碎浆机主要特点是采用了“d”型槽体、节能伏克斯转子，内外双重叶片可节能25%，使废纸与转子的接触更迅速，频率更高，与传统水力碎浆机相比，可缩短废纸碎解时间，在不增加动力和容积的情况下提高生产能力。d型水力碎浆机的转子和出浆盘高出碎浆机槽体底平面，在转子周围形成一个低压流区，使碎解过程中的粗大杂质从重渣口进入沉渣井。
application/features
the main feature of d-type hydrapulper are the use of the d-type groove and the energy saving vieques rotor ,both internal and external leaves 25% energy saving to make waste paper and rotor contact more quickly, more frequently .compared with the traditional hydro-pulper, it could shorten the time of pulp breaking and increase productivity without increasing the volume and momentum..d-type hydro-pulper rotor and the outlet tray is above the pulper tank surface to form a low-pressure flow surrounding the rotor to make the coarse impurities into the dregs well from the heavy dregs mouth with regularly sending under the use of grab.
主要技术参数main technical parameters
|
序号sn |
名 称name |
d型 |
|||||||
|
1 |
有效容积 effective capacity （m3） |
10 |
15 |
20 |
25 |
30 |
|||
|
2 |
生产能力 production capacity（t/d） |
60-90 |
80-120 |
140-180 |
180-230 |
230-280 |
|||
|
3 |
浆料浓度 pulp concentration（%） |
2-5 |
|||||||
|
4 |
电机型号motor model |
y315l1-6 |
y355m1-6 |
y355m2-6 |
y355l2-6 |
yl400-8 |
|||
|
5 |
功率power（kw） |
110 |
160 |
185 |
250 |
280 |
|||
